Sony super HAD color CCD DSP: Sony HQ1 Automatic gain control and BLC Six super long range IR LEDs (ensures four times higher brightness) Unique design Suitable for indoor/outdoor Weather-resistance: IP65 Image sensor: 1/3-inch Sony super HAD CCD (DSP Sony HQ1) Signal system: PAL/NTSC Effective pixels: PAL: 795 x 596 NTSC: 811 x 508 Horizontal resolution: 540TVL Minimum illumination: 0 Lux (IR on) S/N ratio: 48dB (AGC off) Video output: composite 1.0Vp-p at 75Ω White balance: AWB AGC: adjustable Backlight compensation: adjustable Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Gamma correction: 0.45 Synchronization system: internal IR LED: six pieces Lens: 3.6/6mm lens IR viewing distance: 60m Power supply: 12V DC, ±400mA Operating temperature: 10 to 50°C Dimension: 86 x 78 x 132mm Net weight: 1,100g

Camera and brackets incorporate and cable conceal in side of the bracket Protection rate: IP66 Image sensor: 1/3-inch Sony super HAD CCD Horizontal resolution: 480TVL Minimum illumination: 0.1 lux Resolution: PAL: 752 x 582 pixels NTSC: 768 x 494 pixels Signal system: PAL/NTSC IR distance: 20 meters LED: 23 pieces Lens: 3.6/6/8mm lens White balance: auto Scanning system: PAL: 625TVL, 50 fields/second NTSC: 525TVL, 60 fields/second Electronic shutter time (auto): PAL: 1/50 to 100,000 seconds NTSC: 1/60 to 1/100,000 seconds Synchronization system: internal S/N ratio: ≥48dB (AGC off) Operating temperature: -10 to 50 degree Celsius, 95% RH (maximum) Storage temperature: -20 to 60 degree Celsius, 95% RH (maximum) Weight: 400g Dimensions: 125 x 67 x 69mm Power supply: 12V DC, ±10%, 300mA

Features: Exquisite design, precise circuit, structure, incorporated highest technology Aluminum structure, sealed waterproof body sunshield used for outdoor supplied Varifocal lens, easy to fit to wide range of requirements and conditions Longer working distance in night (30 to 35m), best choice for large zone surveillance system such as borders and warehouse Cable conceal inside of the bracket Image sensor: 1/3-inch Sony Specifications: Power supply: 12V DC, 500mA Resolution: PAL: 752 x 582 pixels NTSC: 768 x 494 pixels Horizontal resolution: 540TVL Usable illumination: 0.1 lux Signal system: PAL/NTSC Lens: 3.5 to 8mm manual varifocal lens Angle: 60° Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds S/N ratio: more than 52dB Video output: 1Vp-p/75Ω White balance: automatic Backlight compensation: automatic Gamma characteristic: ≥0.15 LEDs: 42 pieces IR view distance: 30m Weatherproof standard: IP65 Operating temperature: -10 to 50°C Dimensions: 185 x 90 x 96mm Weight: 640g Note: with bracket (cable conceal inside the bracket)

CCD type: 1/3-inch Sony CCD Pixels: PAL: 795 x 596 NTSC: 811 x 508 Horizontal resolution: 540TVL Color: white Scanning system: PAL or NTSC Level synchronization frequency: PAL: 15.625KHz NTSC: 15.734KHz Scanning system: 2:1 deinterlacing S/N ratio: 48dB Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Gamma correction: 0.45 Video output: 1Vp-p and 75Ω AGC: automatic Power supply: 12V DC (±10%) Current: 150mA Carton size: 590 x 360 x 200mm LED: 12-piece of 10mm IR LED IR distance: 80m Manual varifocal lens: 9 to 22mm Dimensions: 672 x 335 x 263mm Weight: 0.26kg Operating temperature: -10 to 45°C

Display: 1/3-inch Sony CCD Horizontal resolution: 480TVL IR lens: 6mm Exquisite design, precise circuit and structure incarnated the highest technology Aluminum structure, all-sealed waterproof body sun shield used for outdoor supplied Applicable in all dark places and indoor or outdoor Signal system: PAL/NTSC Resolution: PAL: 500 x 582 pixels NTSC: 510 x 492 pixels Minimum illumination: 0.5Lux/F1.2 (LED off) and 0Lux (LED on) Day/night automatically switch: illumination 3 to 5Lux/F1.2 White balance: automatic S/N ratio: more than 52dB Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds AGC/BLC: automatic Lens: built-in 6mm (or 3.6, 8, 12 and 16mm lens for optional) IR LED: 30 units, 850nm IR series distance: 25 to 30m IR LED lifespan: 100,000 hours Gamma correction: 0.45 Synchronization mode: internal Video output: composite video output (1.0Vp-p, 75Ω terminated) Power supply: 12V DC ± 10% Operating temperature: -10 to +50?C Humidity: 95% RH (maximum) Body: aluminum Dimensions: 123 x 63 x 63mm Weight: 950g

Cable concealed inside the bracket With adjustable varifocal lens With screws on back panel and plastic rubber to seal 50m visible distance Low power consumption and wide voltage (8 to 15V DC) technology IP55 weatherproof standard Sun-shield housing and aluminum bracket Dust-avoid protect glass OSD menu: 540TVL, motion detection, cover the display area, multiple languages, BLC, AGC and color to B/W adjustable Image sensor: 1/3-inch Sony Horizontal resolution: 540TVL Resolution: PAL: 752 x 582 pixels NTSC: 768 x 494 pixels TV system: PAL/NTSC LED: 48 pieces IR series distance: 50m Synchronization system: internal Usable illumination: 0.1 lux Lens: 4 to 9mm manual varifocal lens S/N ratio: ≥48dB (AGC off) Gamma characteristic: 0.45 Video output: 1.0Vp-p, 75Ω Scanning system: PAL: 625 lines, 50 fields/second NTSC: 525 lines, 60 fields/second Electronic shutter time (automatic): PAL: 1/50 to 100,000 seconds NTSC: 1/60 to 1/100,000 seconds Operating temperature: -10 to +50 degree Celsius, 95% RH (maximum) Storage temperature: -20 to +60 degree Celsius, 95% RH (maximum) Automatic iris: AES White balance: Mode: automatic Range: 3,200 to 10,000K Dimension: 160 x 100 x 97mm Weight: 1,150g Power supply: 12V DC, ±10%, 550mA

Features: Color long range varifocal IR camera Designed for high risk applications Ideal for use in instant deterrent Darkness of image: 40m Designed for internal and external use Wall mounted Cable managed bracket and removable sun/rain shield Anti-explosion capability Omnidirectional adjustable bracket Conveniently installed Specifications: Image device: 1/3-inch Sony CCD sensor Horizontal resolution: 480 and 540TVL Resolution: PAL: 752 x 582 pixels NTSC: 768 x 494 pixels Lens: 3.5 to 8mm Minimum illumination: 0 lux (IR on) S/N ratio: more than 52dB TV signal system: PAL/NTSC Distance: 30 to 40m Viewing angle: 60° LED wavelength: 48 units and 850nm infrared LED Vandal-proof criterion: IP65 Composite video output: 1Vp-p and 75Ω (terminated) Focus mode: manual Average lifespan: 20,000 hours Warranty life: 6,000 hours Power supply: 12V DC and 700mAh (±10%) Operating temperature: -20 to 50°C Gross weight: 1.6kg

Image sensor: 1/3-inch Sony super HAD CCD Signal system: PAL and NTSC Pixels: PAL (H x V): 512 x 582 NTSC (H x V): 512 x 492 Horizontal resolution: 500TV lines Minimum illumination: 0Lux (IR on) S/N ratio: ≥48dB Video output: 1.0Vp-p to 75Ω AGC: on and off switchable White balance: on and off switchable Back light compensation: on and off switchable Exposure mode: EE and AI switchable Electronic shutter speed: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Gamma correction: 0.45 Internal synchronization system IR LEDs: 54 pieces Manual lens: 4 to 9mm IR viewing distance: 40m Power supply: 12V DC±5% and 24V AC switchable Indoor and outdoor installation Operating temperature: -10 to +50°C

Image sensor: 1/3-inch Sony super HAD CCD Horizontal resolution: 420TVL Signal system: PAL/NTSC Lens: 6 to 15mm Minimum illumination: 0 lux (LED on) S/N ratio: more than 52dB BLC: automatic AGC: automatic IR distance: 35 to 40m Viewing angle: 60° LED wavelength: 48pcs 850nm infrared LED Average lifespan: 20,000 hours Water resistance: IP65 Control mode: manual focus Video output: composite video output (1.0Vp-p, 75 ohms terminated) Operating temperature: -20 to 50°C, 95% RH maximum Power supply: 12V DC (±10%)

Image sensor: 1/3-inch Sony CCD Resolution: PAL: 795 x 596 pixels NTSC: 811 x 508 pixels Horizontal resolution: 540TVL Signal system: PAL/NTSC Scanning system: 2:1 interlaced scan Minimum illumination: 0 lux (IR on) Synchronization system: internal S/N ratio: 48dB Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Gamma correction: 0.45 Video output: 1Vp-p, 75 ohms AGC: automatic Lens: 3.6mm fixed lens IR LED: 23EA infrared LED IR distance: 20m infrared LED on Power: 12V DC (±10%) Current: 300mA Working temperature: -10 to 45 degree Celsius

CCD type: color Sony 1/4-inch Resolution: PAL: 512 x 582 pixels NTSC: 512 x 492 pixels Scanning system: PAL and NTSC Horizontal resolution: 420TVL Minimum illumination: 0 lux (IR on) S/N ratio: more than 48dB Video output: 1.0Vp-p, 75Ω Auto AGC, white balance and backlight compensation Internal synchronization Exposure mode: EE Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Gamma correction: 0.45 IR viewing distance: 25 to 30m Lens: 3.6mm (2.8mm optional) Power supply: 12V DC, ±5% Operating temperature: -20 to 50 degree Celsius

CCD type: color Sony 1/3-inch super HAD CCD Pixels: PAL: 512H x 582V NTSC: 510H x 494V Scanning system: PAL/NTSC Horizontal resolution: 420TVL Minimum illumination: 0 lux S/N ratio: more than 48dB Video output: 1.0Vp-p/75 ohms AGC: auto White balance: auto Backlight compensation: auto Exposure mode: auto Electronic shutter: 1/50 (1/60) to 1/100,000 seconds Gamma correction: 0.45 Synchronization system: internal synchronization Auto iris control: no IR LED: 36 pieces, diameter: 8mm IR view distance: 50m Lens: external adjustable 4 to 9mm manual varifocal manual iris lens, with focus and zoom function Power supply: 12V DC Electric current: 500mA (IR on) Operating temperature: -10 to 50 degree Celsius Weatherpoof grade: IP65

CCD type: color Sharp 1/4-inch CCD Pixels: PAL: 500 x 582 NTSC: 510 x 492 Scanning system: PAL/NTSC Horizontal resolution: 420TVL Minimum illumination: 0 lux (IR on) S/N ratio: more than 48dB AGC: auto White balance: auto Backlight compensation: auto Exposure mode: EE Electronic shutter: 1/50(1/60) to 1/100,000 seconds Gamma correction: 0.45 Internal synchronization IR LEDs: 24 pieces IR view distance: 15 to 20m Lens: 6mm (standard) Power supply: 12V DC Operating temperature: -10 to 50 degree Celsius

Image sensor: 1/3-inch Sony Resolution: PAL: 752 x 582 pixels NTSC: 768 x 494 pixels Horizontal resolution: 540TVL Usable illumination: 0.1 lux Signal system: PAL/NTSC Lens: 3.5 to 8mm manual varifocal lens Angle: 60 degrees Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds S/N ratio: more than 52dB Video output: 1Vp-p, 75Ω White balance: auto Backlight compensation: auto Gamma characteristic: ≥0.15 LED: 42 pieces IR viewing distance: 30 meters Weather-resistant standard: IP65 Power supply: 12V DC, 500mAh Operating temperature: -10 to 50°C Dimension: 185 x 90 x 96mm Weight: 640g Note: with bracket (cable conceal inside the bracket)

Lens: 8, 6 and 3.6mm (optional) LED: 48 pieces IR viewing distance: 45m Image sensor: 1/3-inch Sony super HAD CCD Resolution: PAL: 752 x 582 pixels NTSC: 768 x 494 pixels Horizontal resolution: 520TVL Usable illumination: 0.5 Lux (infrared lamps turn on) Signal system: PAL/NTSC Electronic shutter speed: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds S/N ratio: ≥48dB Video output: 1Vp-p, 75Ω White balance: automatic Backlight compensation: automatic Gamma characteristic: ≥0.15 Power supply: 12V DC Operating temperature: -10 to 50°C Dimension: 122 x 82 x 80mm Weight: 679g

Image sensor: 1/3-inch Sony Resolution: PAL: 752 x 582 pixels NTSC: 768 x 494 pixels LED: 26 pieces IR series distance: 25m Weatherproof standard: IP55 Feature: IP55 weatherproof standard Cable conceal inside of the bracket OSD (on screen display function) Motion detection and cover whole display zone With multi-language and BLC, AGC and color to B/W (adjustable) Horizontal resolution: 540TVL TV system: PAL/NTSC OSD menu: yes Lens: 3.6/6mm (optional) S/N ratio: ≥48dB (AGC off) Gamma characteristic: 0.45 Scanning system: PAL: 625TVL, 50 fields/second TSC: 525TVL, 60 fields/second Electronic shutter time: automatic PAL: 1/50 to 100,000 seconds NTSC: 1/60 to 1/100,000 seconds Auto iris: AES White balance: automatic Operating temperature: -10 to 50°C, 95% RH (maximum) Storage temperature: -20 to 60°C, 95% RH (maximum) Mode range: 3,200 to 10,000K Size: 170 x 70 x 120mm Weight: 425g Power supply: 12V DC ± 10%/360mA

Image sensor: 1/4-inch color Sharp Resolution: PAL: 500 x 582 pixels NTSC: 510 x 492 pixels Scanning system: PAL/NTSC Horizontal resolution: 420TVL Minimum illumination: 0 lux (IR on) S/N ratio: more than 48dB Auto AGC, white balance, and backlight compensation Internal synchronization system Exposure mode: EE Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Gamma correction: 0.45 IR viewing distance: 30 to 40m IR LED: 25 pieces Lens: 8mm (standard) Power supply: 12V DC Operating temperature: -10 to +50 degree Celsius

CCD type: color Sony 1/4-inch CCD Pixels (H x V): PAL: 500 x 582 NTSC: 510 x 492 Scanning systems: PAL and NTSC Horizontal resolution: 420TVL Minimum illumination: 0 Lux/F1.2 S/N ratio: more than 48dB Video output: 1.0Vp-p/75 Ohms AGC: auto White balance: auto Backlight compensation: auto Exposure mode: EE Electronic shutter: 1/50 (1/60) to 1/100,000 seconds Gamma correction: 0.45 Synchronized system: internal synchronization IR view distance: 25 to 30, 10 to 15 and 20 to 25m Lens: 6mm Power supply: 12V DC Operating temperature: -20 to 50 degrees Celsius

Image sensor: 1/3-inch Sony Resolution: PAL: (H) 752 X (V) 582 pixels NTSC: (H) 768 X (V) 494 pixels Scanning systems: PAL and NTSC Horizontal resolution: 520TV lines Minimum illumination: 0Lux (IR on) S/N ratio: more than 48dB Video output: 1.0Vp-p, 75Ω Auto AGC, white balance and backlight compensation Exposure mode: EE Electronic shutter speed: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds Gamma correction: 0.45 Internal synchronization IR viewing distance: 50m Lens: 16mm Power supply: 12V DC Operating temperature: -20 to +50 degrees Celsius Working current: 500mA

IR LED: 5 x 36 pieces IR distance: 30m Water resistance: IP66 Automatic white balance (AWB) Adjustable varifocal lens with screws on back panel and plastic rubber to seal, cable conceal inside of the bracket Image sensor: 1/3-inch Sony color CCD Pixels: PAL: 752 x 582 NTSC: 768 x 494 Horizontal resolution: 540TVL Usable illumination: 0.5 Lux (infrared lamps turned on) Signal systems: PAL and NTSC Lens: 4 to 9mm manual varifocal iris lens Electronic shutter: PAL: 1/50 to 1/100,000 seconds NTSC: 1/60 to 1/100,000 seconds S/N ratio: ≥48dB Video output: composite signal 1Vp-p/75Ω Backlight compensation: auto Synchronization system: internal IR power on: CDS auto control Scanning system: PAL: 625 lines, 50 fields/second NTSC: 525 lines, 60 fields/second Gamma characteristic: ≥0.15 LED: 36 pieces IR viewing distance: 30m Power supply: 12V DC, 350mA Operating temperature: -10 to 50?C, 95% RH (maximum) Storage temperature: -20 to 60?C, 95% RH (maximum) Colors: silver and black (optional) Weight: 1,300g Dimension: 142 x 83 x 83mm
