The flashlight shape design, Using alloy material. It is very fashionable and wearable.
D011 will be the world's first Car DVR with the best quality-price relation.
While the batteries are charging, you can take video.
Support PC camera and chatting function.
Support AVI video format.
It can carry out high definition image recording under low illumination.
Support 30 fps for 720*480
Support photograph function, Can take pictures of 1280 * 1024 pixels.
Support USB1.1 and USB2.0.
Support 16GB T-flash card.(maximum)
Build-in lithium battery which can make a video more than one hours, the standby time is up to 100 minute.
II Operation Guide
The battery is built-in lithium rechargeable battery, so when you use it the first time, please charge firstly. The method for charging as following:
2. Indicator light
A. The green indicator light is blinking when photography,; the green light often bright if no card .
B. Blue indicator light: Starting up and reading data, the blue lights up; Shutdown, blue light bright and extinguished.
C. Red indicator light: the red light flashing when charging, the light is off when full charge.
D. Yellow indicator light: the yellow light often bright except shooting model
3. Power on/ Video/Cycling Video
Unscrew back cover, the power switch clicked to open position Press "Video/Camera" button to starting up, Press again start video, the green light blinking. Press "Video/Camera" again , the green light is off and suspend video . Press "Video/Camera" again, Start video again.
4. Take Photo
Unscrew back cover, The power switch clicked to open position Press "Video/Camera" button, enters into standby mode, the yellow light often bright, press PLAY key 2 seconds, the yellow light is off ,D011 enters into shooting model, Press "Video /Camera". Once took a picture. green light flash one time.
5. Video/Camera when charging
Unscrew back cover, the power switch clicked to open position. contact charge,the yellow light often bright, the red light blinking. The red light is off when full charge.
In the standby status, Holding "Video/Camera" 5 seconds, blue light is on and off immediately. Then the machine is turned off.
If the power switch clicked to off position Press, D011 will cut off completely. You need set time again when next use.
There is a CD with the product which contains a file named time synchronization file. Please copy it to TF card. When connect D001 with computer, whose time will be displayed with computer synchronously.
8.Auto-power off function
MINI DV will save file and turn off automatically as following:
It can connects computer under power off mode, standby mode or video mode, after that which can be used as U disk, who can copy, cut and paste, delete file.
When you connect it with USB port, a portable disk mark will be seen after several seconds. Red indicator light always brights, yellow indicator light will be from flashed quickly to always brights.
When you first use PC camera, please install driver. The driver name is SPCA1528_V2220_M^Setup.exe, which is placed in attached CD. When you install please double press this document, and as per guide to do. After that there will be an AMCAP icon on the computer desk.
Under power off or power on mode, use USB cable to connect computer, the mode is U disk mode. Then short press "VIDEO/CAMERA" button, at this moment it can be switched into PC camera mode. Then double press AMCAP icon can be used as PC camera.
