Description:
Full HD HDD Media Player with HDMI, HDMI HDD player, media HDD player, multimedia HDD player, HDMI media player, TV HD Media Player
§ Hot Spot
1) Sigma SMP8635c
2) HDMI 1.3 / H. 264 support
3) YpbPr / RGBHV / S-Video
4) USB Host & Slave
5) Coaxial / Optical / Stereo SPDIF
6) Coaxial 5.1 digital audio output
7) DTS Decoding Board function(Optional)
8) Cooling system: Active cooling system with high quality silent fan
9) Black and White Color Options
§ Specifications:
- CPU: Sigma Design SMP8635 c
- Cooling: Active cooling using a high quality silent fan.
- EMS memory: 256Mbyte DDR RAM, 32Mbyte Flash ROM
- Video decode formats: H. 264, VC1, MKV, MPEG-1, MPEG-2, MPEG-4, DIVX, XVID, MOV, AVI, ISO
- Audio decode formats: Flac, MPEG Audo layer 1&2, MP3, OGG, AC3, AAC, WMA, WMA RPO, DD5.1, DTS original data output
- Photo Format: JPEG, BMP, PNG, GIF File
- Other formats: ISO, IFO
- System Format: EXT3; NTFS/FAT32
- Subtitle Format: SRT SSA SUB SMI
§ I/O Ports:
- 2x USB 2.0 Host ports (supporting playing the media files from external CD ROM/DVD ROM/Portable HDD/USB storage/WiFi card
- 1x USB 2.0 Slave device port to connect PC.
- 1x 10/100Mbps auto Ethernet port: For streaming video files.
- 1x SATA interface on the right side.
§ A/V Ports:
- HDMI 1.3 (digital video and audio signals)
- Component(YPbPr)
- Composite Video output
- Coaxial SPDIF
- Optical SPDIF
- 5.1 Analog audio(Audio FR/FL, SR/SL, C, SW)
§ Human interface:
- Remote Control (standard configuration)
- Language supported: English, Chinese, German, French, Italian, Czech, Swedish, Spanish, Polish, Portuguese, Bulgarian, Norwegian, Hungarian, Slovenian, Greek, Russian, Dutch.
- Power Supply: AC 100V-220V, DC 12V 3A
- Standard Accessories: Remote, AC/DC Power Adapter, AC power cord, HDMI cable, USB Slave cable, SATA cable, - - -- User's Manual
- Unit's Dimension: 162 X 130 X 50(MM)
